CPU ซีพียู AMD RYZEN 7 9700X 8C/16T UP TO 5.5GHz

General Specifications

Name : AMD Ryzen™ 7 9700X

Family : Ryzen

Series : Ryzen 9000 Series

Form Factor : Desktops , Boxed Processor

Market Segment : Enthusiast Desktop

AMD PRO Technologies : No

Regional Availability : Global

Former Codename : Granite Ridge AM5

Architecture : Zen 5

# of CPU Cores : 8

Multithreading (SMT) : Yes

# of Threads : 16

Max. Boost Clock : Up to 5.5 GHz

Base Clock : 3.8 GHz

L1 Cache : 640 KB

L2 Cache : 8 MB

L3 Cache : 32 MB

Default TDP : 65W

Processor Technology for CPU Cores : TSMC 4nm FinFET

Processor Technology for I/O Die : TSMC 6nm FinFET

Package Die Count : 2

Unlocked for Overclocking : Yes

AMD EXPO™ Memory Overclocking Technology : Yes

Precision Boost Overdrive : Yes

Curve Optimizer Voltage Offsets : Yes

AMD Ryzen™ Master Support : Yes

CPU Socket : AM5

Supporting Chipsets : A620 , X670E , X670 , B650E , B650 , X870E , X870 , B840 , B850

CPU Boost Technology : Precision Boost 2

CPU Cooler : No

Instruction Set : x86-64

Supported Extensions : AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64

Thermal Solution (PIB) : Not Included

Recommended Cooler : Premium air cooler recommended for optimal performance

Max. Operating Temperature (Tjmax) : 95°C

Connectivity

Native USB 3.2 Gen 2 (10Gbps) : 4

Native USB 2.0 (480Mbps) : 1

PCI Express® Version : PCIe® 5.0

Native PCIe® Lanes (Total/Usable) : 28 , 24

Additional Usable PCIe Lanes from Motherboard : X870E 8x Gen4

X870 4x Gen4

X670E 12x Gen4

X670 12x Gen4

B650E 8x Gen4

B650 8x Gen4

NVMe Support : Boot , RAID0 , RAID1 , RAID5 , RAID10

System Memory Type : DDR5

Memory Channels : 2

Max. Memory : 192 GB

System Memory Subtype : UDIMM

Max Memory Speed : 2x1R DDR5-5600

2x2R DDR5-5600

4x1R DDR5-3600

4x2R DDR5-3600

ECC Support : Yes (Requires mobo support)

Graphics Capabilities

Graphics Model : AMD Radeon™ Graphics

Graphics Core Count : 2

Graphics Frequency : 2200 MHz

USB Type-C® DisplayPort™ Alternate Mode : Yes

Key Features

Supported Technologies : AMD EXPO™ Technology , AMD Ryzen™ Technologies

Warranty : 3 Years
