Dual-axis button rocker PS2 game joystick sensor

Dual-axis button rocker PS2 game joystick sensor

Description:

This is PS2 game joystick module for Arduino

Lots of robot projects need joystick. This module provides a affordable solution to that. Simply connect to two analog inputs, the robot is at your commands with X,Y control. It also has a switch that is connected to a digital pin. This joystick module can be easily connect to Arduino by normal IO Expansion Shield with supplied cables.

No soldering required, Reusable for prototyping or design applications of electronic circuit,modify or revise the circuits easily.

Accept resistors,transistors, diodes, LEDS, capacitors and other types of electronic components.

An invaluable tool for experimenting with circuit designs whether in the RD.

Directional movements are simply two potentiometers - one for each axis

Compatible with Arduino interface

Brand: KEYES

Model: KY-023

Specification:

Three axis (X,Y,Z(button))

Size:37x25x32mm

Weight: 15 g

Documents

WikiDoc

Tie-point 700

ABS plastic material

Completely reusable

Phosphor bronze nickel plated spring clips

Accepts a variety of wire sizes(29-20 AWG)

// Henry's Bench

// Module KY023

int Xin= A0; // X Input Pin

int Yin = A1; // Y Input Pin

int KEYin = 3; // Push Button

void setup ()

{

pinMode (KEYin, INPUT);

Serial.begin (9600);

}

void loop ()

{

int xVal, yVal, buttonVal;

xVal = analogRead (Xin);

yVal = analogRead (Yin);

buttonVal = digitalRead (KEYin);

Serial.print("X = ");

Serial.println (xVal, DEC);

Serial.print ("Y = ");

Serial.println (yVal, DEC);

Serial.print("Button is ");

if (buttonVal == HIGH){

Serial.println ("not pressed");

}

else{

Serial.println ("PRESSED");

}

delay (500);

}
