TADA MK54P 3IN1 โคมPVC โคมพาร์ ไฟพาร์ LED TA DA ดวงไฟ 54 ดวง 3 IN 1 MK-54P MK 54P เอไอ-ไพศาล

TADA MK54P 3IN1 โคมPVC

DMX Channel List

7Chanal

No. Function Description

CH1 Master Dimmer Full dimmer of red,green,blue,white From dark to bright

CH2 R Dimmer Red dimmer from dark to bright

CH3 G Dimmer Green dimmer from dark to bright

CH4 B Dimmer Blue dimmer from dark to bright

CH5 Master strobe R,G,B Full Strob light, from slow to fast

CH6 Function

0-50: DMX dimmer:

51-100 Color output (8 colors);

101-150: Jump change;

151-200:Gradual change:

201-250: Pulse change;

251-253: voice-active strob,vioce control color chang:

CH7 Speed Function Speed from slow to fast (Choose color at color output function)

3CH

NO. Function Description

CH1 R Dimmer Red dimmer from dark to bright

CH2 G Dimmer Green dimmer from dark to bright

CH3 B Dimmer Blue dimmer from dark to bright

LED Display

No. Menu Value Function

1 d001 000-512 Color seting DMX512 address-mode 3Chanels

2 A001 000-512 DMX512 Address code seting-Mode 7 Chanels

3 r255 000-255 Red dimmer from dark to bright

4 G255 000-255 Green dimmer from dark to bright

5 b255 000-255 Blue dimmer from dark to bright

6 FH255 000-255 Strobe from slow to fast

7 CL99 01-99 8 Color Output

8 CC01 01-08 Color jump chang from slow to fast

9 DE99 01-99 Color gradual chang from slow to fast

10 CP99 01-99 Color pulse chang from slow to fast

11 SU01 01-02 Mode;1 is strob light voice active color chang

Special function

Press and hold the Menu key and do not release it until r005 appears and the first digit flashes,then release the key, press MENU to chang Function number ,Use the UP or DOWN key to select ,pless the ENTER key ,save the seting and exit.

NO. MENU Velue Function

1 r255 005-255 Current seting red,small to large,dark to bright

2 G255 005-255 Current seting Green,small to large,dark to bright

3 b255 00-255 Current seting blue,small to large,dark to bright

4 -rGb - Press the established for emit lighe in3 color,double clik on the UP button to remotely synchronize the current from the machine to other macine though the signal line
